What is the function of a manual butterfly valve

What is the function of a manual butterfly valve? Manual butterfly valves are typically used in industrial production pipelines as control components of the pipeline. The role of manual butterfly valves is very significant. They can cut off the flow of the medium in the pipeline or regulate the size of the medium flow in the pipeline.

At present, manual butterfly valves have been widely applied in the production pipelines of general industries such as water conservancy projects, water treatment, petroleum, chemical engineering, and urban heating, as well as in the condensers and cooling water systems of thermal power stations.

The function of the manual butterfly valve can be summarized as:

1.When used for flow regulation, the butterfly valve needs to adjust the flow under special working conditions, or in an environment with strict requirements for sealing performance, or in a working environment with severe wear, low temperature and other harsh conditions. In the above-mentioned situations, a specially designed metal-sealed three-eccentric dedicated butterfly valve with a regulating device should be used.

2. Double eccentric butterfly valves are suitable for use in pipelines of urban heating, gas supply, water supply and other projects as regulating and throttling devices. The applicable media include oil products and acidic or alkaline substances. The sealing performance of the double eccentric butterfly valve is not good. It is applied in pipelines that allow a certain amount of leakage. If the pipeline needs to ensure sealing performance, a triple eccentric butterfly valve should be used.

3. Soft-sealed butterfly valves have excellent sealing performance and are suitable for pipelines that require complete sealing and zero leakage. Soft-sealed butterfly valves have good sealing performance, but they are greatly affected by temperature. The working temperature range of rubber soft-sealed butterfly valves is 0-80℃, while that of fluorine-lined soft-sealed butterfly valves is between -10 and 150℃. Soft-sealed butterfly valves are suitable for media such as fresh water, sewage, seawater, brine, steam, oil products and other weak acid and alkali media.

4. Butterfly valves, especially the double eccentric butterfly valves and triple eccentric butterfly valves among hard-sealed butterfly valves, are suitable for making large-diameter valves. Double eccentric butterfly valves are suitable for the opening, closing and regulation of ventilation and dust removal pipelines. They are widely used in ventilation and dust removal pipelines in the metallurgical industry, light industry, power industry, petrochemical industry, etc. The application fields of the triple eccentric butterfly valve are more extensive. It not only inherits the advantages of high temperature and high pressure resistance of the metal hard-sealed butterfly valve, but also has the excellent sealing performance of the soft-sealed butterfly valve. It is a good alternative to gate valves, globe valves and ball valves.
